Products Description :

Spark pure sine wave inverter offering quality true sine wave output, it is designed to operate popular power tools and sensitive loads. Connect Spark 3000W pure sine wave inverter with battery terminals, then you can get AC power for your appliances, the AC output identical to, and in some cases better than the power supplied by your utility.

Products Features :
– Input & output fully isolated.
– High Surge: high surge current capability starts difficult loads such as TVs,camps,motors and other inductive loads.
– Grounding Protection: Has ground connection on casing.
– Soft start: smooth start-up of the appliances.
– Pure sine wave output waveform: clean power for sensitive loads.
– AC output identical to, and in some cases better than the power supplied by your utility.
– Cooling fan works automatically when inverter becomes too hot or you plug is high load, will turn off automatically when the temperature is reduced or load disconnected.
– Low total harmonic distortion: below 3%.
– 2 Amp USB charge port. Charge you mobile devices using the USB port.
– Two LED indicators on the front panel show the working and failure state.

– Remote LCD with ON/OFF switch.

SPECIFICATION：

Output Power (continuous): 3000W

Maximum Active Surge Rating (less than 1 second) :6000W

AC Output Voltage (idle) :230/240 VAC +/-3V

Output Frequency: 50Hz +/-1Hz

Output Waveform: True/pure sine wave (<3% THD)

Efficiency: 90≥% (12V DC)

No Load Current Draw (DC side) <1A (battery voltage dependent)

WARNING:

DO NOT use appliances which are rated more than 3000W or you will damage the inverter this includes inductive loads eg microwaves,

DO NOT ATTEMPT to use this with cigarette lighter socket. You will burn car wiring.

CONTENTS IN BOX:

Power inverter

Battery leads.

general User manual
